An essential part of developing glasses-free 3D screens, the 3D lens allows for high-quality simultaneous effects to be enjoyed without the necessity of extra glasses. As display technology has progressed quickly, these lenses have transformed the way people see in many fields, such as manufacturing, health care, and stimulation.
Key components of E3D glasses-free 3D screen
- Lenticular Lens (3D lens): One essential component of glasses-free 3D displays is the lenticular lens. It creates the illusion of distance by using small cylindrical lenses to divide a picture into two distinct fields of view, one for the left eye and one for the right. Transparent polymers with high refractive indices are the usual materials for 3D lenses, which provide less dispersion and improved clarity. These lenses complement LCD screens beautifully, allowing users a genuine three-dimensional viewing experience without any extra hardware.
- Glass substrate: The LCD panel and optical components are supported by the glass substrate, which also serves as a structural base. Superior opacity and stability are achieved by using high-quality optical glass or quartz glass. The transfer of optical impulses, which enable a clear and sharp display, is greatly facilitated by this substrate.
- Liquid crystal panel: A liquid crystal panel includes colour filters, polarization plates, liquid crystal molecules, and driving circuitry. It displays graphics by manipulating the polarization of light. When used in conjunction with a 3D lens, it guarantees accurate left-and right-eye picture separation, producing a genuine three-dimensional effect.
- Backlight system: The LCD panel is uniformly illuminated by the backlight system, which improves the contrast and brightness of the display. The efficiency, low power consumption, and extended lifespan of LED backlights make them the primary choice for modern glasses-free 3D displays. For maximum efficiency, the backlight system and LCD panel are integrated.
- Power supply: To keep the 3D lens and its accessories working, a reliable power source is required. A high-voltage circuit for the lighting system and an AC-to-DC power-switching supply circuit make up the whole thing. Consistent picture quality is free of flashing or distortion is guaranteed with a dependable power source.
Main Modules
GAMA Module
Grayscale correction, which improves the 3D image’s contrast and depth, is the responsibility of the GAMA module. Improved picture clarity and authenticity are the results of this module’s adjustments to the gamma curve, which guarantee an accurate display of grayscale tones.
Module for TCON
The picture signals’ timing and synchronization are controlled by the TCON (Timing Controller) module. This module displays the left and right eye images at the correct intervals and makes sure they are completely aligned to keep the 3D impression smooth.
DC/DC adapter
The LCD screen and backlight system are supplied with a stable voltage by the DC/DC module, which is a power conversion system. It improves display performance while decreasing power consumption and ensuring all components are working at their best.
Collaboration between components
An effective glasses-free 3D screen will have all of its parts work together without any problems. To get a stereoscopic vision, the lenticular 3D lens splits the images from the LCD. Uniform illumination is guaranteed by the backlight technology, which enhances the level of illusion. The drive system coordinates all of these parts to provide a complete viewing experience, while the power module ensures consistent functioning. To guarantee signal accuracy and long-term durability, these optical components are supported by a glass substrate.
